| 安裝環境Installation environment | 室內Indoor |
| 安裝方式Installation | 無基坑安裝, 高80MM No foundation pit installation, high 80MM |
| 安裝空間installation space | 1030X860MM |
| 外形尺寸outline dimension | 1010X800MM |
| 平臺尺寸Platform size | 700X720MM |
| 頂層高度Top level | ≮2300MM |
| 停層站 Stop Station | 最大2層站Maximum 2-storey station |
| 最大高度maximum altitude | 最大12米Maximum 12m |
| 標準層高Standard level | 標準層高3.5米/每層 Standard layer 3.5 m high/per layer |
| 出入方向 Access directions | 180°貫通/ 90°/或原進原出 180°through /90°/ or original in / out |
| 電源power | 1.5KW/AC220V/50HZ家用 (domestic) |
| 驅動方式Driving mode | 液壓驅動hydraulic pressure |
| 運行速度running speed | 80-120MM/秒100MM/sec |
| 層門控制gate control | 手動+閉門器 Manual door closers |
| 控制方式control method | 點動 按住運行/自動Click Hold down run / auto |
| 轎廂側板Car side | 5+5鋼化夾膠玻璃或鋁板噴塑 5+5 toughened with glue glass or aluminum |
| 轎廂門 Car door | 5MM鋼化玻璃5MM tempered glass |
| 控制電壓control voltage | 24V/DC |
| 整機顏色Machine color | 標準色：白色（可選）Standard Color: White (optional) |
| 最大承重Maximum load bearing | 250KG/350KG |
| 設備噪音noise | 小于60dB Less than 60 dB |
| 工作溫度working temperature | -5C°/ +40C° |
安全裝置
safety device | * 手動應急下降及開門裝置 Manual emergency drop and door opening device
* 平臺主控面板優先 Platform master panel preferred
* 緊急停止按鈕 Emergency stop button
* 轎門與設備聯動控制 Car door and equipment linkage control
* 轎廂底部防撞Car bottom collision
* 轎廂頂部防撞 Car roof collision
* 防墜落機械裝置 anti-fall mechanical device
* 電控系統防過流過載保護
Electronic control system to prevent overcurrentoverload protection
* 平臺超重保護 Platform Overweight Protection
* 液壓油路防爆閥 Hydraulic oil circuit explosion-proof valve |
